Swing rod bearing grease injection machine

Swing rod bearing grease injection machine - Introduction: The company is committed to being a manufacturer of swing rod bearing grease injection machines, serving our customers with excellence and quality first

Equipment process flow:

Weighing before grease injection → Automatic single-sided point finding for grease injection → Weighing after grease injection → Removal of NG products → Homogenization of grease → Product delivery → Manual inspection and pallet loading

Parameter indicators:

(1) The grease injection tolerance is ± 2%, and 50 sets of continuous normal operation are all within the tolerance range;

(2) Electronic scale accuracy 0.01g

Function description:

(1) Fat injection: Adopting a single-sided grease injection form, using non-contact optical fiber positioning. After the optical fiber finds the grease injection position, the motor drives the grease injection head to rotate to the designated position and then drop the grease injection to prevent the grease injection head from pressing the product during grease injection. The material requirement for the grease injection head is brass;

(2) Weighing inspection: High precision electronic scales are used to weigh the product before and after grease injection, with an accuracy of 0.01g;

(3) Uniform grease: using electric drive to rotate the inner or outer ring of the bearing to achieve uniform grease effect;

1. Intelligent equipment for swing rod bearing grease injection machine
